IPC6312LFW-AX4C-VG Active Deterrence IP PTZ with Alarm, Strobe Siren and Motion Tracking

Call For Price

  • Call or Log In for Dealer Price

  • Active Deterrence
  • Alarm and Strobe
  • Motion Tracking
  • IP66 Protection



IPC6312LFW-AX4C-VG Active Deterrence IP PTZ with Alarm, Strobe Siren and Motion Tracking

The IPC6312LFW-AX4C-VG Active Deterrence IP PTZ is designed to stop crime before it happens. This new Lighthunter Mini PTZ from Uniview has a number of unique features you can count on to deter intruders from your property or facility. Most of you have likely seen motion detection floodlights that come on when motion is detected. The IPC672 operates on the same principal, but attached to a Full HD PTZ Camera! Adding this Camera to your security solution is almost like hiring a guard but you only have to pay them once. It detects the intruder, warns them, tracks them and records them. When you deploy this IPC6312LFW-AX4C-VG Active Deterrence IP PTZ, you will deter crime BEFORE it happens!

The IPC6312LFW-AX4C-VG is the replacement for the IPC672LR-AX4DUPKC

Active Deterrence Features

  • Motion Tracking
  • Alarm Siren
  • Strobe Light
  • Voice Alarm
  • Built in two way Audio

Active Deterrence Alarm

The purpose of active deterrence is that once a stranger enters the view of the camera, a strobe light will be triggered and a built-in speaker plays a voice suitable for different scenes. Therefore, the Active Deterrence Mini PTZ camera can be used for discouraging unwanted intrusions. You can use the PTZ in parking lots, to remind pedestrians not to walk in certain areas. In addition to perimeter detection purposes, it is suitable for villas, construction sites, and private property. Motion Tracking means the PTZ will follow the intruder wherever they go. Pan, Tilt, and Zoom functions are motorized and automatically focus in on the motion detected. The Mini PTZs built-in speaker will play a voice “Alert area, go out of here as soon as possible” when an intruder wants to enter the forbidden area.

Unique Video Surveillance Applications

Compared with traditional video surveillance, the active deterrence mini PTZ can actively prevent unwanted intrusions by strangers or those wanting to do harm. Once it detects the intruders, the PTZ will trigger the strobe light and audio alarm. This feature serves two main functions. First, the intruder knows they have been noticed and are far more likely to leave the area immediately. Second, the person now knows they are on video surveillance which stops intruders before they attempt to enter the prohibited area.

How the Active Deterrence Mini IP PTZ works

In order to deter intruders accurately, the active deterrence mini PTZ is aimed to detect human body so it filters the false alarms by small animals or other irrelevant objects. The siren is designed with Red and Blue lights for better impact. In addition, when an intrusion occurs, the two strobe lights will turn on to provide you with a clear image. Furthermore, the built-in MIC & speaker makes it easy for you to remotely communicate with people in front of the camera. The PTZ has 4X Motorized Zoom, IP66 weatherproof design, and can be used in outdoor applications such as apartments, factories, and construction sites.

About Lighthunter Technology

Lighthunter Technology from Uniview sets a new standard for low light image quality. More light is allowed to enter the lens therefore more detailed images are captured in low light environments. Since a great majority of events happen at night, you want a security cameras that can deliver great images even in the dark, right? If you have ever noticed some of the grainy night time images on the TV Crime shows, then you know how frustrating the images are. With Lighthunter Technology, images are delivered clearly, without the graininess and in better detail!

Learn More about Lighthunter Technology Here: Lighthunter Technology and Teleview


Uniview SD Card

On Board Storage (Edge Storage)

This Uniview Active Detereence Mini PTZ Camera has a MicroSD Card slot for On board Recording. On board recording can be used as a redundant video storage with data saved even if network connection is lost.


True WDR

True WDR

The IPC6312LFW-AX4C-VG Active Deterrence IP PTZ Camera has True 120dB WDR (Wide Dynamic Range). Scenes with a variable range of light are difficult for most cameras. However, with True WDR Cameras, scenes are rendered in full detail for bright and dim areas simultaneously. This is especially helpful in applications such as entry ways where you may have dim lighting indoors, but your doorway or windows have bright sunlight. See our sample image below!


UNV Cameras are packed with advanced features are among the easiest systems to install that we have seen. The Prime Series Cameras and NVR’s from Uniview are Plug and Play IP! Uniview Cameras and NVR’s have been installed in major applications around the world. We are pleased to be a Uniview Distributor and be able to offer professional IP Solutions that are Feature Packed and affordable.


IPC6312LFW-AX4C-VG Active Deterrence IP PTZ Quick Specs:

  • 2MP, 1/2.8″ CMOS Sensor
  • LightHunter illumination
  • Intelligent Perimeter Protection, Line Crossing, Enter or Leave Area
  • Smart Intrusion Prevention uses target classification to reduce false alarms
  • Up to 50 m (164 ft) IR and 10m (33 ft) warm light distance
  • Up to 120 dB Optical WDR(Wide Dynamic Range)
  • Intelligent Face Capture
  • IR anti-reflection window to increase the infrared transmittance
  • 2D/3D DNR (Digital Noise Reduction)
  • Ultra 265,H.265, H.264, MJPEG
  • Built-in microphone & speaker
  • Alarm Light
  • Built In Strobe
  • Triple streams
  • ROI (Region of Interest)
  • ONVIF Conformance
  • Support PoE power supply
  • Wide temperature range: -20°C ~ 60°C (-4°F to 140°F)
  • Wide voltage range of ±25%
  • IP66



Compatible NVR’s In Our Store: All Uniview NVR’s

Other Compatible NVR’s: ONVIF Compliant NVR’s

Mounting Options:




TR-UP06-B-IN Pole Mount Bracket





TR-JB07-D-IN Junction Box






TR-UP06-C-IN Pole Mount Bracket



TRCMo6-A Ceiling Mount Bracket



TR-CM06-D Ceiling Mount Bracket








Why we like the IPC6312LFW-AX4C-VG Active Deterrence IP PTZ with Alarm, Strobe

GDPR Ready

Uniview IP Cameras and NVR’s are GDPR Compliant



3 YEAR Manufacturers Warranty
Free Lifetime Tech Support
Money Back Guarantee


Not Sure About Your Product or Compatibility? Ask an Expert!


Additional information

Weight 14 lbs
Dimensions 16 × 14 × 12 in

Lens Focal Length

Sensor Type

Night Vision Range

Camera Type

Weatherproof Rating

Camera Resolution

Supported Formats

Special Features

, , , , ,


Downloadable PDF specifications for this product:

UNV IPC6312LFW-AX4C-VG 2MP LightHunter Active Deterrence PTZ Camera V1.6-EN

UNV EZView Mobile Surveillance App Datasheet



Camera Installation Guide

UNV Network Cameras User Manual

OutDoor Mini PTZ Camera Auto Tracking Usage Instructions-V1.0
